Product Description:
The Material Level Switch series features a side-mounted installation option and can be constructed from either 304 or 316L stainless steel, with an optional Teflon coating for added protection. The product offers multiple output signal options including relay, PNP/NPN transistor, and can be used in hazardous environments as it is explosion-proof.
With its high precision and accuracy, the Material Level Switch Series is an excellent choice for a variety of industries, including food and beverage, pharmaceuticals, and chemical processing. Its reliable performance ensures that you can monitor your materials with confidence.
Technical Parameters:
| Technical Parameter |
Description |
| Material of Construction |
304 or 316L Stainless Steel, Optional Teflon Coating |
| Mounting Type |
Side-mounted or Top-mounted |
| Response Time |
≤0.5 Seconds |
| Operating Pressure |
Up to 2 MPa (may vary by model) |
| Ingress Protection Rating |
IP68 |
| Power Supply |
24V DC, 220V AC, or 110V AC |
| Process Connection |
Threaded, Flanged, or Tri-clamp |
| Measurement Medium |
Powders, Granular Solids, Liquids |
| Weight Density Range |
Suitable for materials with a density above 0.5 g/cm³ |
| Fork Length |
Ranges from 40mm to 1000mm (varies by model) |
| Sensitivity Adjustment |
Yes |
| Liquid Level Detection |
Yes |
| Sensitivity Adjustment |
Yes |
Applications:
The material level switch series product is widely used for powder detection, making it an ideal solution for industries that require accurate and reliable powder level detection. The product features a tuning fork level switch that can detect the level of solid materials. The product is available in side-mounted or top-mounted mounting types, making it easy to install in various applications.
The DX-TFLS131 material level switch series product is made in China and has an ingress protection rating of IP68, making it suitable for use in harsh environments. The product has an output signal of relay, PNP/NPN transistor, and a process connection of threaded, flanged, or tri-clamp. The fork length ranges from 40mm to 1000mm, varying by model, allowing users to choose the best option for their specific needs.
The material level switch series product is perfect for use in various industrial applications such as food processing, chemical production, and pharmaceutical manufacturing. It can accurately detect the level of solid materials, ensuring that the production process runs smoothly without any interruptions. The product is highly reliable, making it a cost-effective solution for businesses.
Support and Services:
The Material Level Switch Series product technical support and services include:
- Assistance with product installation, configuration, and calibration
- Troubleshooting and diagnosis of product issues
- Recommendations for product maintenance and repair
- Assistance with product upgrades and firmware updates
- Access to product documentation and manuals
- Training and education on product usage and applications
